CPU Support
|
AMD® AM4 RYZEN™ & A Series / Athlon Processors
on Socket PGA 1331
|
Chipset
|
AMD® B370 Chipset
|
Memory
|
4x DDR4 DIMM Slots for stock clocked DDR4-2666 / 2400 / 2133 RAM
64GB Maximum (4x 16GB)
Overclocking support for DDR4-3200 & 2933MHz RAM
Supports ECC and non-ECC, Un-buffered Memory
(Only supports ECC Modules in non-ECC mode)
|
|
|
Expansion Slots
|
1x PCI-E 3.0 / 2.0 x16 slot
1x PCI-E 3.0 / 2.0 x16 slot (in x4 mode)
1x PCI-E 2.0 x1 slot
|
Multi-GPU Support
|
Supports AMD CrossFireX™ Technology
|
Display Interface
|
AMD Ryzen™ CPUs do no support Motherboard Video Ports
|
|
|
Storage
|
4x SATA 6Gb/s ports w/ Raid 0, 1, 10 support
1x M.2 Socket 3, with M key, type 2242 / 2260 / 2280
(SATA & PCIe 3.0 x4 modes available)
|
|
|
LAN
|
Realtek® RTL8111H Chipset:
1x Gigabit RJ45 LAN port
|
|
|
Audio
|
Realtek® ALC 887 8-Channel High Definition Audio CODEC:
3x 3.5mm Audio Out jack
|
|
|
USB
|
2x USB 3.1 Type-A Gen2 (10Gbps) ports (Teal)
4x USB 3.1 Type-A Gen1 (5Gbps) ports
2x USB 2.0 Type-A (480Mbps) ports
2x USB 3.1 Type-A Gen1 (5Gbps) ports at mid board
4x USB 2.0 Type-A ports (480Mbps) at mid board
|
|
|
Back Panel I/O
|
2x USB 3.1 Type-A Gen2 (10Gbps) ports (Teal)
4x USB 3.1 Type-A Gen1 (5Gbps) ports
2x USB 2.0 Type-A (480Mbps) ports
1x RJ45 Gigabit LAN (RJ45) port
3x 3.5mm Audio jack
1x PS/2 keyboard/mouse combo port
1x DisplayPort port*
1x HDMI port*
1x D-Sub VGA port*
*(These Video Ports are not used by Ryzen™ CPUs; a discrete Video Card is required)
|
|
|
Internal I/O Connectors
|
1x Fan RGB header
1x USB 3.1 Gen 1 connector support 2x USB 3.1 Gen 1 ports (19-pin)
2x USB 2.0 connectors support 4x USB 2.0 ports
1x M.2 Socket 3 with M Key, type 2242 / 2260 / 2280 / 22110 (SATA mode & PCIe x4 modes)
1x COM port(s) connector
6x SATA 6Gb/s connectors
1x CPU Fan connector (1x 4-pin)
2x Chassis Fan connectors (2x 4-pin)
1x S/PDIF out header
1x 24-pin EATX Power connector
1x 8-pin ATX 12V Power connector
1x Front panel audio connector (AAFP)
1x System panel
1x Clear CMOS jumper
1x Speaker connector
|
|
|
BIOS
|
128 Mb Flash ROM, UEFI AMI BIOS, PnP,WfM2.0,SM BIOS 3.0, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, My Favorites, Last Modified log, F12 PrintScreen, ASUS DRAM SPD (Serial Presence Detect) memory information, F6 Qfan Control
|
Manageability
|
WfM 2.0, DMI 3.0, WOL by PME, PXE
|
|
|
Operating System
|
Only supports Windows® 10, 64 bit
|
|
|
Form Factor
|
micro ATX Form Factor: 244 x 244mm
|
|
|
Dimensions (LxW)
|
244 x 244mm
|
Weight
|
N/A
|
