Printing Technology |
Digital LED Electrophotographic Printing Technology |
Print Resolution |
600 x 2400 dpi
600 x 1200 dpi
600 x 600 dpi
Physical dot pitch: 600 dpi |
Warm-up Time |
Approx. 19.0 seconds from power-on
Approx. 19.0 seconds from power save |
First Print Out Time |
Approx. 5.0 seconds |
Print Speed |
A4(Landscape) 35 ppm
A3 20 ppm |
Interface |
100BASE-TX/10BASE-T, USB 2.0 (High Speed), IEEE1284-1994 Bi-directional Parallel, USB 2.0 (High Speed) Host |
Protocol |
TCP/IP, IPX/SPX |
Printer Language |
PCL 6 (XL) emulation, PCL 5e emulation, IBM ProPrinter emulation, Epson FX Emulation |
Supported OS (Click here for latest OS) |
Windows 7, Windows 7 x64, Windows Vista, Windows Vista x64, Windows XP, Windows XP x64, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, Windows Server 2003, Windows Server 2003 x64, Mac OS X 10.6, Mac OS X 10.5, Mac OS X 10.4 |
Memory (Std./Max.) |
128MB/640MB |
Font |
PCL emulation 87 scalable fonts, 4 bitmap fonts |
Paper Size |
A3, A4, A5, A6, B4, B5, B6, Letter, Legal 13, Legal 13.5, Legal 14, Executive, Envelopes, Custom Size: Width 148-297 mm x Length 182-420 mm |
Paper Weight |
Tray 1 : 60 - 176 gsm
(Optional)Additional Tray : 60 - 176 gsm
Multi-purpose tray : 60 - 200 gsm |
Input Capacity |
Tray 1 : 530 sheets
(Optional)Additional Tray : 530 sheets
Multi-purpose tray : 100 sheets |
Output Capacity |
Face Down : Max. 250 sheets
Face Up : Max. 100 sheets |
Dimensions(WxDxH) |
485 x 450 x 373 mm |
Weight(includes supplies) |
Approx. 24.0 kg |
Weight(not includes supplies) |
Approx. 22.0 kg |
Operating Environment |
Operating: 10 - 32 °C, 20 - 80 %RH
Storage: 0 - 43 °C, 10 - 90 %RH
No condensation |
Power Source |
Single phase 220 - 240 VAC ±10%, 50/60 Hz ±2% |
Power Consumption |
Operating: Max. 1,200W / Ave. 550W
Idle: 75W
Power Save: 15.0W
Deep Sleep: 1.2W |
Safety & Environment Regulation |
CCC Mark |
Noise Level |
Operating :Approx. 54 dBA
Idle: < 37 dBA |
Duty Cycle |
Recommended: 20,000 pages/month
Maximum: 100,000 pages/month |
In the Box |
Manuals, Starter toner cartridge x 1, Image Drum x 1, Power cable, CD-ROM, Others |
