Model |
Black: NSE-200-KKN1 / Brown: NSE-200-KWN1 |
Available Color |
Midnight Black / Chocolate |
Materials |
Plastic bezel with mesh, steel case body |
Dimensions (W x H x D) |
202 x 378 x 445 mm / 7.9 x 14.9 x 17.5 inch |
Net Weight |
4.3 kg / 9.5 lbs |
M/B Type |
microATX, Mini-ITX |
5.25" Drive Bays |
1 (Max. length of 5.25" device: 170mm / 6.7 inch) |
3.5" Drive Bays |
3 |
2.5" Drive Bays |
4 |
I/O Panel |
N200: USB 3.0 x 1, USB 2.0 x 2, Audio In & Out
N200 Advanced: USB 3.0 x 2, USB 2.0 x 1, Audio In & Out
N200 Chocolate: USB 3.0 x 2, USB 2.0 x 1, Audio In & Out |
Expansion Slots |
4 |
Cooling System |
Top: 120mm x 15mm fan x 1 (optional)
Front: 120mm black fan x 2 (one XtraFlo is pre-installed)
Rear:120mm black fan x 1 (XtraFlo pre-installed)
*The bundled XtraFlo fans: 3-pin
Side: 120mm fan x 1 (optional) |
Power Supply Type |
ATX PS2 (Max. length: 180mm / 7.1 inch) |
Maximum Compatibility |
CPU cooler height:
w/o 120mm x 25mm side fan: 160mm / 6.3inch
with 120mm x 25mm side fan: 140mm / 5.5inch
*Side panel with stamping
Graphics card length: 355mm / 14 inch |
